AV 5.1k
1650 W POWER AMPLIFIER
AV 5.1k, 1650 W (RMS) max, five-channels: with its hybrid design, it is the specialist amplifier for front + rear + subwoofer or multi-amplified front + subwoofer systems.
Its high-quality AB Class output stage provides two channels with 250 W (RMS), combined with another pair of A class pure audio channels rated at 75 W (RMS), perfect for active two-way front speaker systems. The D Class mono section provides 1000 W (RMS) for an efficiency and powerful subwoofer output. AMP (Amplifier Management Processor) constantly checks the operating status system and communicates with the user through 4 different coloured LEDs, located on the top panel; ART (Automatic Remote Turn On-Off) allows automatic turn-on/off when a remote signal isn’t available from the source.
Related products
-
THG 3.0 II optional mesh grilles can be defined with only one word: unique. They are made with finest steel without any compromise, to overcome the absolute.
-
THG 1.5 II
THG 1.5 II optional mesh grilles dedicated to TH 1.5 Violino can be defined with only one word: unique. They are made with finest steel without any compromise, to overcome the absolute.Comp Tweeter
Size 38 mm (1.5″)
Power Handling 200 (Hi-Pass filtered @ 1,8kHz – 12 dB Oct.) W peak
Impedance 6 Ohm
Frequency Response 800 ÷ 26k Hz
Sensitivity 93 dB/Spl
Magnet N38 “H-grade” Neodymium
Dome Tetolon fibre
-
Technical Data
Comp Midrange
Size 70 mm (3″)
Power Handling 55 W Continuous Powerzdx
110 W Peak Power
Impedance 4 Ω
Frequency Response 110 ÷ 5700 Hz
Sensitivity 85,6 dB/Spl
Magnet N38 “H-grade” Neodymium
Cone TPX®
