- Rockford Fosgate contact and radio flashing information
- M5-800X4:
- 4-Channel powersports amplifier
- 11″ Power/ground/turn-on & speaker output harness (installed on amp)
- 11″ Input harness (installed on amp)
- Two 14″ RCA-to-Molex input adapters
- Power/ground/turn-on adapter plug
- Two 7.5″ speaker output harnesses
- 3mm Allen key
- TMS65:
- Two 2-way speakers
- 2 Street Glide grilles
- 2 Road Glide grilles
- 2 Tour-Pak grilles
- Installation manual (En/ Fr/ Sp/ Others)
- RFK-HD14M5:
- 1 Amp mounting bracket
- 1 Heatsink
- 34″ T-harness
- 65″ Power/ground harness w/ inline 60A Maxi fuse
- 20″ Amplifier output harness
- 12″ Amp output harnress
- 16″ Fairing harness
- 2 Amp output Y-adapters
- 5 Amp bypass plugs
- Eight 8″ wire-ties
- 4 Threaded post adapters
- Two 16mm bolts
- Four 18mm counter-sunk screws
- Four 10mm counter-sunk screws
- Four 8mm hex-socket screws
- 2 Flange-nuts
- Installation guide
Description
Product highlights:
- system includes two 6-1/2″ fairing speakers, a 4-channel amp, and an amp wiring kit
- designed for select 2014-up Harley-Davidson models
Rockford Fosgate TMS65 6-1/2″ full-range speakers
- designed for your Harley’s fairing speaker locations
- Element-Ready design is weather- and water-resistant
- power handling: 75 watts RMS (150 watts peak)
- warranty: 2 years
Rockford Fosgate M5-800X4 marine/powersports 4-channel amplifier
- Class AD amp technology
- 100 watts RMS x 4 at 4 ohms (400 watts peak)
- conformal-coated circuit board — suitable for power sports and marine applications
- twin cooling fans and real-time thermal sensing
- includes Rockford Fosgate RFK-HD14 amplifier kit
- radio must be re-flashed by an authorized Rockford Fosgate motorcycle audio dealer.
- MFR # HD14-STG2
